RAM Powered Dock for the Panasonic Toughbook Field & Health Series

No other dock for the Panasonic CF-H1 is easier to use than this. With one hand, you can easily insert or remove the Toughbook. The unique spring loaded latch and roller system perform flawlessly together and the overall shape of the dock does not block any functions. The built in combination lock adds security so your MCA is there when you need it. Additional features include 5 USB hubs, Ethernet, Serial, VGA, and Power.
RAM offers mounting systems to meet a wide range of medical and field applications. This one of a kind docking solution for the
Panasonic CF-H1 mounts to any flat surface alone or can be mated to a RAM rubber ball and socket system for unmatched ergonomics
and viewing angles. No matter whether the MCA will be used in the ER, a doctors office, or ambulance, RAM has what you need to mount
the Panasonic CF-H1 exactly where you want it. Keep it safe, secure, and ready with RAM.
This powered dock is designed to hold the following devices:
Panasonic Toughbook CF-H2 Field
Panasonic Toughbook CF-H2 Health
Panasonic Toughbook CF-H1 Field
Panasonic Toughbook H1 Health
Features:
1. (5 qty) USB Ports
2. RJ-45 LAN Connector
3. Power Input
4. VGA Output
5. DB9 RS232 Serial Port
6. Audio Out
7. Dial combination lock
Material:
High Strength Composite
Regulatory Approvals:
CE
FCC
TUV-CB
e-Mark
Note:
The RAM-2461 (75mm X 75mm VESA plate) is used to connect to the back of the Powered Dock & is not included with the purchase of the RAM-HOL-PAN5P.
